Flowmeter for Coffee Machine, Water Flow Sensor for Espresso Coffee Maker (FM-01)

Flowmeter for Coffee Machine Detect Water Flow Water Sensor for Espresso Coffee Maker (FM-01)

Flowmeter for Coffee Machine, Water Flow Sensor for Espresso Coffee Maker (FM-01)

Material Flow meter body: PBT 30%GF Connector: 3.96mm pitch 3-way connector, 1.14mm Copper with Tin plating Seal: Silicon Propeller: PP Magnet: SrFeO Electrical connection specification Supply voltage: 3.8 - 20 VDC Consumption: 5 mA max. Signal voltage: Taken from Ground. Leakage current: 10µA max. Signal load: 20mA max. Signal: Square wave Duty cycle: 50% Technical Specification Measuring accuracy: ± 2% (Repeatability per unit) Total tolerance: ± 5% (Production deviation) Operating fluid: Water Operating temperature: -10 to 65 °C Operating pressure: -1 to 0.3 bar Mounting: Horizontal position Connector: D6.0 mm inlet / D6.0 mm outlet Nozzle size: D 1.2mm Flow rate: 0.20-0.35 liters/min

Key Features

• ✅ A flow meter designed for coffee machines which use vibratory pumps, detects water flow through the whole tubing.
• ✅ Fit for all kinds of coffee maker.
• ✅ Flow rate: 0.20-0.35 liters/min
• ✅ Flowmeter for Coffee Maker Detect Water Flow
• ✅ Water Sensor for Espresso Machine

✅ Product Dimensions: 3.35 x 2.95 x 1.77 inches
